Technical specifications voltage-clamp

• Open input (RMS) noise:
  • 0.89 pA rms @ 2.6 kHz

• Current ranges: ±10 nA (Gain 200 MΩ; BW 2.6 kHz), ±40 nA (Gain 50 MΩ; BW 19.2 kHz), ±400 nA (Gain 5 MΩ; BW 80 kHz)
• Customizable voltage protocols for pulse generator in the range of ± 500 mV
• Digital filters: Cutoff frequencies in the range between 1.25 kHz and 40 kHz
• C-fast compensation range: 0.2 – 52.8 pF
• C-Slow compensation range: C in 0.3 – 269 pF, τ in 0.5 – 1280μs
• R series correction range: in 0.4 – 25.6MΩ
• R series prediction range: R in 0.2 – 51.2MΩ,  τ in 2-512μs

Technical specifications current-clamp

• Noise (rms): 6.6 μV @ 5 kHz
• Customizable current protocols for pulse generator in the ranges ±2 nA (res. 0.5pA); ±8nA (res. 2pA)
• Voltage range: ±250 mV
• Pipette neutralization (3 – 285.2 pF range)
• True-zero current mode

Other technical specifications

• Max available bandwidth: 80 kHz
• Max sampling rate: 160 ksps
• 4 programmable digital input/output ports
• Data output format .abf
• 5Vdc power supply
• Dovetail mounting
